UL 1642 Lithium Battery Drop Tester For Battery Drop Strength Test Drop Height 30～1500mm

Name: UL 1642 Lithium Battery Drop Tester For Battery Drop Strength Test Drop Height 301500mm
Brand: Sinuo
Price: 1 USD

UL 1642 Lithium Battery Drop Tester For Battery Drop Strength Test Drop Height 30～1500mm Manufactures

Brand Name : Sinuo

Model Number : SN5510

Certification : Calibration Certificate (Cost Additional)

Place of Origin : China

MOQ : 1

Price : Customized

Payment Terms : T/T

Supply Ability : 20 Sets Per Month

Delivery Time : 30 Days

Packaging Details : Plywood Case

Control Method : PLC control

Drive Mode : Stepper motor

Test station : 1 station

Power supply : AC220/50Hz

Drop height : 30～1500mm

Lifting speed : 0～3mm/s

Brand : Sinuo

Warranty : 1 year

Contact Now

UL 1642 Lithium Battery Drop Tester For Battery Drop Strength Test Drop height 30～1500mm

Product Information:

This test equipment is used to test the drop strength and safety requirements of batteries.

Technical Parameters:

Item	Parameters
Power supply	AC220V±10%/50Hz
Test station	Single station
Operation interface	7-inch color LCD touch screen
Drive mode	Stepper motor
Control system	PLC Control
Drop height	30～1500mm, can be preset
Lifting speed	0～3mm/s, can be preset
Test environment	Ambient temperature 5～40°C; relative humidity (20～90)%RH. Use place: no violent shaking, vibration, no electromagnetic interference, no dust, no explosive and corrosive gas, good heat dissipation

Feature:

1.This machine available for package face, corner, edge free drop testing.

2.With height digital display instrument and tracing height with encoder, so can measure the precision drop height.

3.The drop height tolerance within2% or 10mm;

4.Adopt pneumatic structure, fix the specimen with special fixture (range adjustable), push the drop button, pneumatic cylinder open, specimen free dropping. The drop height controllable, and with height steel ruler which makes drop height available. Various kinds drop floor optional. Meets different testing standards.
